Marp: Markdown Presentation Ecosystem¶
What is Marp?¶
Quote
Marp (also known as the Markdown Presentation Ecosystem) provides an intuitive experience for creating beautiful slide decks. You only have to focus on writing your story in a Markdown document.
Here you find a few good references if you wish to get started using Marp:
- https://marp.app/
- https://marpit.marp.app/
- https://chris-ayers.com/2023/03/31/customizing-marp
- https://www.youtube.com/watch?v=EzQ-p41wNEE
How to build a cool presentation¶
Marp is a really powerful tool to build an HTML presentation using Markdown. It can be developed inside VS Code (see e.g. https://www.youtube.com/watch?v=EzQ-p41wNEE) and the HTML can be directly exported there.
Let me give you an example presentation that shows how easy it is:
Example:¶
---
paginate: true
marp: true
theme: uncover
class: invert
style: |
.small-red-text {
font-size: 0.75rem;
color: red;
}
h1 {
font-size: 60px;
}
h2 {
font-size: 50px;
}
h3 {
font-size: 40px;
}
h4 {
font-size: 30px;
}
h5,h6,p,li,code,table {
font-size: 25px;
}
headingDivider: 1
math: mathjax
---
# **Marp**
Markdown Presentation Ecosystem
https://marp.app/
# How to write slides
Split pages by horizontal ruler (`---`). It's very simple! :satisfied:
```markdown
# Slide 1
foobar
# Slide 2
foobar
```
Alternatively, set the **directive** [headingDivider](https://marpit.marp.app/directives?id=heading-divider). To automatically split at `h1` headers add to the document metadata:
```md
headingDivider: 1
```
# Markdown !!!
*Just* **write** `Markdown` ==here==!!!
- Bullet 1
- Bullet 2
### Subtitle
[Marp Link](https://marpit.marp.app/)
**Emojies**: :joy: :wink: :smile: :rocket:
# Markdown !!!
#### Use automatic syntax highlighting
```python
def foo(bar: str) -> str:
return bar.strip()
if __name__ == "__main__":
main()
```
# Markdown !!!
### Tables
| Syntax | Description | Test Text |
| :--- | :----: | ---: |
| Header | Title | Here's this |
| Paragraph | Text | And more |
# Markdown !!!
## Crazy Math
<!-- _footer: You have to add **math: mathjax** to the document metadata -->
$$
f(a) = \frac{1}{2 \pi i} \oint_\gamma \frac{f(z)}{z-a} dz
$$
# Custom Backgrounds
Use **Image Directives** (local or web-resource):
```md
```
# Custom Backgrounds
**Multiple Backgrounds!!!**
```md
```
# Images
Put Images to the left
```md
```
# Images
... or to the right
```md
```
# Images
... or adjust the width ...
```md
```
# Images
... or apply filters:
```md
```
# GIFS !!!
```
```
# Mermaid Support
<!-- Add this anywhere in your Markdown file -->
<script type="module">
import mermaid from 'https://cdn.jsdelivr.net/npm/mermaid@10/dist/mermaid.esm.min.mjs';
mermaid.initialize({ startOnLoad: true });
</script>
<div class="mermaid">
journey
title My working day
section Go to work
Make tea: 5: Me
Go upstairs: 3: Me
Do work: 1: Me, Cat
section Go home
Go downstairs: 5: Me
Sit down: 3: Me
</div>
# HTML Support
Add custom CSS to document metadata
```
---
marp: true
style: |
.small-red-text {
font-size: 0.75rem;
color: red;
}
---
# Title
<div class="small-red-text"> Small Red Text</div>
```
<div class="small-red-text"> Small Red Text</div>
# HTML Support
<div id="myDiv"> </div>
<script src='https://cdn.plot.ly/plotly-2.24.1.min.js'></script>
<script src='https://cdnjs.cloudflare.com/ajax/libs/d3/3.5.17/d3.min.js'></script>
<script>
d3.json('https://raw.githubusercontent.com/plotly/plotly.js/master/test/image/mocks/sankey_energy.json', function(fig){
var data = {
type: "sankey",
domain: {
x: [0,1],
y: [0,1]
},
orientation: "h",
valueformat: ".0f",
valuesuffix: "TWh",
node: {
pad: 15,
thickness: 15,
line: {
color: "black",
width: 0.5
},
label: fig.data[0].node.label,
color: fig.data[0].node.color
},
link: {
source: fig.data[0].link.source,
target: fig.data[0].link.target,
value: fig.data[0].link.value,
label: fig.data[0].link.label
}
}
var data = [data]
var layout = {
title: "Energy forecast for 2050<br>Source: Department of Energy & Climate Change, Tom Counsell via <a href='https://bost.ocks.org/mike/sankey/'>Mike Bostock</a>",
width: 1000,
height: 500,
font: {
size: 10
}
}
Plotly.newPlot('myDiv', data, layout)
});
</script>
# Fragmented lists
Use `*` to get a fragmented list, where each item appears one after each other and `-` to directly display all items.
### Non-Fragmented
- non-frag 1
- non-frag 2
### Fragmented
* frag 1
* frag 2
# Speaker Notes
Just add **Speaker Notes** via:
```html
<!--
Some notes here that might be useful.
-->
```
<!--
Some notes here that might be useful.
-->
# Directives
<!-- _backgroundColor: #180f61 -->
With `Directives`, it is easy to modify the behaviour of **Marp** for a single slide or the whole presentation.
#### Local Directives
Using local directives (prepend with `_`), one can modify a single page, e.g.
```html
<!-- _backgroundColor: #180f61 -->
```
#### Global Directives
Using global directives, one can modify the bejaviour of the slides from the current slide on
```html
<!-- backgroundColor: aqua -->
```
